R10 Multi-function Fall/Falling out of Bed/Sleep Assist Detection Radar

Health Care

R10 Multi-function Fall/Falling out of Bed/Sleep Assist Detection Radar

Communication mode: 4G full network access, Wifi

Power supply: Type-C 5V 2A

Working frequency: radar 60 GHz, gateway 433MHz, WiFi/BT 2.4GHz

Complete machine specifications: D88×25 (mm)

Installation method: ceiling installation, hanging height 2.2-3m (sleep detection requires side installation)

Working temperature: -20~55℃

Environmental humidity: 10%~95% RH

Other functions: voice recognition, active rescue, voice call, accessory access

Leave a message JT-9292 Long Distance UHF RFID Integrated Reader(Multi-tag)

Contact

R10 Multi-function Fall/Falling out of Bed/Sleep Assist Detection Radar

Overview

Communication mode: 4G full network access, Wifi

Power supply mode: Type-C 5V 2A

Working frequency: radar 60 GHz, gateway 433MHz, WiFi/BT 2.4GHz

Machine specifications: D88×25 (mm)

Installation method: ceiling installation, hanging height 2.2-3m (side installation is required for sleep detection)

Working temperature: -20~55℃

Environmental humidity: 10%~95% RH

Other functions: voice recognition, active help, voice call, accessory access

R10 function introduction

Fall auxiliary detection–installed in the bathroom, living room and bedroom, etc., to assist in the detection of accidental falls/falling out of bed. No need to wear, no sense of use.

Gateway function–supports access to various 433Mhz sensors. With the A20D multi-function fall detection sub-machine, it can realize the whole house fall auxiliary detection and one-click call safety protection.
